100hp Skid Steer Loader JS100X
100hp Skid Steer Loader JS100X
Compact structure, maneuverable movement suitable for narrow Space operation
Close cabin with joystick control system
Gear type transmission
Double accelerograph control
Multi-function with a wide range of attachments
Hydraulic brake
Close cabin with joystick control system
Gear type transmission
Double accelerograph control
Multi-function with a wide range of attachments
Hydraulic brake
Model | JC100X |
Rated Operating Capacity | 1200 |
Tipping load(Kg) | 2400 |
Bucket Capacity(m3) | 0.5 |
Lifting Force(Kg) | 2730 |
Hydraulic Pump Flow(L/min) | 75/125 |
Engine power(HP) | 100 |
Weight(Kg) | 3800 |
Max. Travel Speed(km/h) | 12/18 |
Grade ability(° ) | 20 |
Tire | 12-16.5 |
Fuel/hyd. Oil capacity(L) | 90/90 |
A. Height at Maximum Extension | 40700mm |
B. Hinge Pin Height | 3150mm |
C. Total Height | 2160mm |
D. Length with Bucket | 3580mm |
E. Length without Bucket | 2880mm |
F. Width with Bucket | 1900mm |
G. Track Width | 1500mm |
H. Wheelbase | 1020mm |
J. Ground Clearance | 260mm |
K. Dumping Angle ° | 40 |
L. Dumping Height | 2450mm |
M. Maximum Reach | 700mm |
