System

48V/4KW Series

48V/4KW Sepex

48V/5KW AC System

Key Components

Battery

8xT105(185Ah@5hr   rate)

8xT105(185Ah@5hr   rate)

8xT105(185Ah@5hr   rate)

Motor

3.8KW Chinese   motor

3.8KW Chinese   motor

5KW AC Motor

Controller

Curtis 1204   (275A@2minutes)

Curtis 1268   (400A@2minutes)

Zapi ACE2

(400A@2minute)

Performance

Passenger   capacity

6

6

6

Range (loaded)   based on flat road at a speed of 20km/h (km)

>75

>75

>90

Max. speed   @12.49:1 gear ratio

32

32

32

Minimum turning   radius (m)

4

4

4

Max. climbing   ability (loaded)   @ 12.49:1 gear ratio

20%

20%

20%

Max. movement   after brake at speed of 20km/h

≤4m

≤4m

≤4m

Max. loading   weight

530kgs

530kgs

530kgs

Net weight

715kgs

715kgs

745kgs

Dimensions

Overall   dimensions (mm)

3750X1400X1810

Min. ground   clearance (mm)

140

Wheelbase (mm)

2450

Front wheel   tread (mm)

1160

Rear wheel   tread (mm)

1150
