100Ton Off-road Crane
100Ton Off-road Crane
100T Rough Terrain Crane RT100
Max. lifting height main boom extended: 45.6m
Four-wheel drive and four-wheel steer chassis;
Fully hydraulic steering system;
Cummins electronically-controlled engine
Superior pick-and-carry ability during short-distance transit can bring great convenience to the users.
Digital display ensure the safety and high efficiency of the operation
Max. lifting height main boom extended: 45.6m
Four-wheel drive and four-wheel steer chassis;
Fully hydraulic steering system;
Cummins electronically-controlled engine
Superior pick-and-carry ability during short-distance transit can bring great convenience to the users.
Digital display ensure the safety and high efficiency of the operation
| Model | RT75 | RT75 |
| Max. rated lifting weight × working radius (kg.m) | 75000×3.0 | 100000×3.0 |
| Max. lifting moment of basic boom(kN.m) | 2814 | 3339 |
| Max.lifting moment of longest boom(kN.m) | 1184 | 1388 |
| Max. lifting height of longest boom(m) | 41 | 45.6 |
| Max. lifting height of jib(m) | 56.8 | 63 |
| Outline dimensions (L×W×H)(mm) | 14897×3395×3840 | 14247×3620×3960 |
| Distance between outriggers (Longitudinal × transversal)(mm) | 7380×1300 | 8000×7900 |
| Main boom length (completely retracted – completely extended)(mm) | 12500-38500 | 10800-34000 |
| Jib length (completely retracted – completely extended)(mm) | 10000-170000 | 10000-170000 |
| Main boom angle of elevation(°) | -3～78 | -3～78 |
| Swing range | 360°continuously | 360°continuously |
| Max.speed of single rope on the drum of main winch(m/min) | 125 | 125 |
| Boom extension time(s) | 110 | 170 |
| Boom retraction time(s) | 90 | 158 |
| Boom derricking up time(s) | 80 | 82 |
| Boom derricking down time(s) | 70 | 69 |
| Swing speed(r/min) | 0～2 | 0～1.5 |
| Rated working pressure(MPa) | 29 | 30 |
| Rated working flow(L/min) | 320 | 500 |
| Hydraulic oil tank capacity(L) | 1000 | 1200 |
| Complete vehicle kerb mass(kg) | 52840 | 65000 |
| Front axle load(kg) | 27760 | 33200 |
| Rear axle load(kg) | 25080 | 31800 |
| Max. traveling speed (forwards / backwards)(km/h) | 36/36 | 24/15 |
| Wheelbase(mm) | 4150 | 4600 |
| Treads (front / rear)(mm) | 2632 | 2860 |
